Automatic label inspection machine


描述

描述

Automatic label inspection machine

Product Application

This machine is suitable for inspecting all kind of label, printed material ,etc .It supports meter counting ,pcs counting , rewinding by motor ,speed adjustable , foot control switch ,etc. worker can sit to operate .

SPECIFICATIONS FOR VISUAL LABEL INSPECTING WITH REWINDING MACHINE
Model
JM-350L
Voltage
220V
Power
0.5KW
Working width
350 mm
Max. unwinding diameter
500 mm
Max. Rewinding diameter
500 mm
Inspection table size
360×800 mm
Dimension
1330x650x1000 mm
Gross weight
200 KG
Detailed Images

Unwind Parts

This parts is used as unwinding part , the tension is control by manual . The max. unwinding diameter is 500 mm . 3″ paper core is suitable .

Inspecting table

inspecting table , worker can sit beside the table and check the label and find the defect parts by eyes , there are lights from both upside and downside .

Pcs counting sensor

This sensor is used to finish piece counting .

Rewinding part

This unit is used to rewinding the finished labels .

Our Company
JiuMu Machinery (Kunshan) Co.,Ltd. comprise research ,development ,production ,sale and service as one of professional electronic products machinery manufacturing company .



We focus on automatic cutting machine ,slitting machine ,laminating machine for many years, five experienced engineers are on service .R&D department is responsible for developing new product according to customers’ needs

Jiu Mu machinery (kunshan ) Co., ltd , It has its own processing workshop, part of the components were purchased from the outside suppliers , assembly workshop, program debugging. So we have large power to customize machine for customers .

Customer visiting from all over the world

CE Certificate for label inspecting with rewinding machine ,counting function

If you want to ask for quotation about counting function label inspecting with reverse rewinding machine  ,please tell us details information as much as you can ,so we can quote to you as soon as possible .

Buying Guides for visual label inspecting with reverse rewinding machine meter counting function
Material
Pictures are appreciated if possible
Diameter
ID & OD
Thickness
mm
Weight
KG
Length you want to cut
mm
Width
mm
Packing & Delivery
Packaging
Packaging Details
The normal package  for visual label inspecting rewinding machine is plywood case . It does not need Fumigation .It’s easy for forklift to upload and download .Safety transportation .,we will use PE film for packing first before plywood case or pack it according to customers special request.
Our Service

After sale service for our counting function visual label inspecting rewinding machine is as follow :

1. Free sample testing and video for your reference

2. Prompt delivery within 24 hours

3. One year warranty ,whole life technical support

4. Free training in our factory available before delivering machines

5. Engineers available to service machinery overseas

6. Technical support: Professional engineers team to help you design a drawing of machine to get highest profit with lowest cost and offer you technical support any time.

7. Other demanded spare part or equipment support: Plenty of cooperated professional supplier for spare parts or other necessary equipment make it possible for us to offer our customers big convenience to complete their production line in high quality with low cost in a short time.

8.Every  customer can get one piece of  English operation manual , a total working video for machines ,details on every button function ,normal notice when operation .
